No. 9155. Ryan YO-51 Dragonfly US Army Air Corps
Source unknown

Ryan YO-51 Dragonfly

07/31/2009. Remarks by Johan Visschedijk: "The OY-51 was designed to an USAAC specification for a two-seat army co-operation and artillery observation aircraft with STOL capabilities, alike the Fieseler Fi-156 Storch. Ryan started development in 1938 and to achieve the STOL goals the aircraft was fitted full-span slots to the leading edge of the wings and Fowler flaps of very wide chord to the trailing edge.

Ryan YO-51 Dragonfly
(Johan Visschedijk Collection)

Three aircraft were ordered by the USAAC from Ryan at San Diego, California, in 1939, s/n 40-703, 40-704, and 40-705. Powered by a 440 hp Pratt & Whitney R-985-21 Wasp Junior they were flown in 1940. Test results confirmed the calculated performance, however, the USAAC contract for series production went to the competing Stinson O-49. In October 1941 the three YO-51s were relegated to ground instructional airframes."

Ryan YO-51 Dragonfly
(Johan Visschedijk Collection) APS No. 174

Ryan YO-51 Dragonfly
(Johan Visschedijk Collection) APS No. 760

Ryan YO-51 Dragonfly
(Johan Visschedijk Collection) APS No. 1302
Ryan YO-51 Dragonfly


Created July 31, 2009
